MIX 10 NG2 – RS 232 Interface
7.4

Specifications of the RS 232 Interface

Speed 9600 Baud
Data format 1 start bit, 8 data bits, 1 stop bit, no parity
Handshake none
Sub-D 9 Pin 2 = Rx
Pin 3 = Tx
Pin 5 = GND
The data exchange between the MIX 10 NG2 and the superior control is done via two-byte commands which are integrated in a data packet
with subsequent check sum.
The structure of the commands is as follows:
Device –> PC
DLE STX
0x10 0x02
PC –> Device
DLE STX
0x10 0x02
Hex Abbrev.
0x10 DLE
0x02 STX
0x01 Dev. No
- Len
- Cmd
Data
0x03 ETX
- Check Sum
Received Commands
The following commands are received from the MIX 10 NG2:
Cmd Data0 Data1
A1 00~04
A2 00~4F 00~04
A3 00~4F 10~15
A6 00~1F 00~04
2 6 Bit 6
01.02.2008 10:30 Uhr Seite 28
Device No. Len Cmd
0x00 (Cmd+Data)
Device No. Len Cmd
0x01 (Cmd+Data)
Designation Description
Data Link Escape Control character, which indicates that a defined number of following
characters has another meaning e.g control information
Start of Text Designates the start of the actual message and the end of the "Header"
Device Number States the device ID
Length States the length (byte) of the actual command (Cmd+Data) – normally
0x02 or 0x03
Command Refer to the following tables
Refer to the following tables
End of Text Designates the end of the message to be transmitted.
Check Sum XOR control byte to recognise if the command has been transmitted
correctly
Command
Select line source
Set stereo volume to value "N"
Set mic volume to value "N"
Change stereo volume by "N"-steps
Higher or lower
Data DLE ETX
0x10 0x03
Data DLE ETX
0x10 0x03
Data0 Data1
line 1 - 4 or none(0)
N stereo no
N mic no
N stereo
0 = higher, 1 = lower
28
Check Sum
Check Sum
