Sub Group Output

The sub group output (9), +6 dBu, is a balanced output (3-pin terminals) for the connection to an external output amplifier. Here are all
microphone and line signals as a master which are routed via the Dip switches to the sub group output. The sub group output (L/R) is adjusted
with the volume control (4) on the front or via the supplied software. The sub group output (9) is suitable for using long cables.
4.7

Mains

The power cable is connected to the mains (10). When you connect the device to the mains make sure that the mains voltage of the
MIX 10 NG2 corresponds to the local mains voltage.
5.

Allocation of the Input Channels via Dip Switches

The Dip switches are used to allocate the input channels to the master output (M) or sub group output (S). If the Dip switch is set to the top,
the input channels is routed to the approriate output. This allows allocating separate signals to the different output zones (sub group (S) /
Master (M)).
6.

Setting up

After all connections have been made (mains, microphone etc.), follow these steps to set up the system:
1. Reduce the gain (to minimum) of the amplifier/power amplifier connected to the MIX 10 NG2 and switch it off.
2. Set all volume controls on the front to the very right (maximum).
3. Turn on the MIX 10 NG2 with the on/off switch (7).
4. Speak at an appropriate distance into the microphone connected first and open the gain control on the rear until the audio LED (6) will
illuminate clearly when speaking up.
5. Repeat this procedure with all connected microphones.
6. Set all volume controls on the front into a 3/4 opened position.
7. Turn on the connected power amplifier and increase its input gain until the desired volume is achieved.
8. Fix this setting of the power amplifier. The fine tuning can be done with the control on the front of the MIX 10 NG2.
7.

Remote Control via RS 232

To operate and configure the MIX 10 NG2 via a PC or media control system, the MIX 10 NG2 is equipped with an RS 232 connection
(9-pin Sub D, male).
7.1

Software Installation

The supplied software serves for the configuration and remote control of the MIX 10 NG2.
The software operates under Windows
screen.
7.2

Connection

Connect the remote connection (11) with a standard RS 232 connecting cable to the serial RS 232 interface of your PC.
Carefully select the cable length of the RS 232 connection. Inefficient PC interfaces and poor cables can considerably affect the
communication / performance.
