MIX 10 NG2 – RS 232-Schnittstelle
Cmd
Data0
Data1
A7
00~1F
10~15
2
6
Bit 6
A8
00~02
A9
00~01
10~15
AA
00~01
01~02
AB
00~03
00~01
AE
00~01
00~04,10~15
AF
01
02
00~04
03
10~15
06
01~02
07
00~04,10~15
B0
00~7F
B1
00~7F
B2
00~7F
B3
00~4F
B4
00~7F
B7
00~03
B8
00
BF
00
01
02
03
04
05
06
07
08
„10" ~ „15" steht für Kanäle MIC1~MIC6
„00"~ „04" steht für die Kanäle LINE, SUB-L, SUB-R, MASTER-L,MASTER-R.
Lautstärke-Skalierung (hex):
00 ... 20
N x (-0,5 dB)
21 ... 40
N x (-1,0 dB) + 16,0 dB
41 ... 4E
N x (-2,0 dB) + 80,0 dB
4F ... 7F
-104 dB = mute
01.02.2008
10:29 Uhr
Seite 13
Command
Change mic volume by "N"-steps
Higher or lower
Ducking manually
Mic ducking
Stereo ganged
Recall or save preset
Mute channel
Inquiry
Inquiry
Inquiry
Inquiry
Inquiry
Fade-out speed
Fade-in speed
Ducking threshold
Ducking attenuation
Ducking hold
Switch-on status
Reset EEPROM
Inquiry
Inquiry
Inquiry
Inquiry
Inquiry
Inquiry
Inquiry
Inquiry
Inquiry
Data0
Data1
N
mic no
0 = higher, 1 = lower
02 = on
00 = off
01 = enabled
mic no
00 = disabled
01 = enabled
01 = subgroup
00 = disabled
02 = master
00 = recall
preset number
01 = save
00= unmute
stereo / mic no
01 = mute
select line source
stereo volume
stereo no
mic volume
mic no
stereo ganged
01 = subgroup , 02 = master
mute state
stereo / mic no
speed value
speed value
threshold value
attenuation value
value
preset 1/2/3/switch-off
status(0)
fade-out speed
fade-in speed
ducking threshold value
ducking stereo reduction
ducking hold
ducking fade-out speed
ducking fade-in speed
start configuration
programmed version
13
