MIX 10 NG2 – RS 232-Schnittstelle
Sendebefehle
Folgende Befehle werden vom MIX 10 NG2 gesendet:
Cmd
Data0
Data1
C1
00~04
C2
00~4F
00~04
C3
00~4F
10~15
C4
00~4F
00~04
C5
00~4F
10~15
2
0
Bit 0
C8
2
1
Bit 1
C9
00~01
10~15
CA
00~01
01~02
CB
00~03
00~01
CE
00~01
00~04,10~15
D0
00~7F
D1
00~7F
D2
00~7F
D3
00~4F
D4
00~7F
D7
00~03
D8
„10" ~ „15" steht für Kanäle MIC1~MIC6.
„00" ~ „04" steht für die Kanäle LINE, SUB-L, SUB-R, MASTER-L,MASTER-R.
Eine Bestätigungsnachricht (Acknowledge) wird vom MIX 10 NG2 direkt nach Empfang einer Anforderung gesendet.
Beispiel:
Auswahl des CD-Line Eingangs
PC –> Device / Gerät
DLE
STX
10
02
01.02.2008
10:29 Uhr
Seite 14
Command
Line source selected
Stereo volume currently adjusted
value "N"
Mic volume currently adjusted value
"N"
Stereo volume now value "N"
Mic volume now value "N"
Auto ducking
Ducking manually
Mic ducking
Stereo ganged
Load or save preset
Mute flag
Fade-out speed
Fade-in speed
Ducking threshold value
Ducking reduction
Ducking hold
Switch-on status
Programmed version (V 1.0)
Device No.
Len
Cmd
01
02
A1
Data0
Data1
line 1 - 4 or none(0)
N - value
stereo no
N - value
mic no
N - value
stereo no
N - value
mic no
1 = on , 0 = off
1 = on , 0 = off
01 = enabled ,
mic no
00= disabled
01 = enabled ,
01 = subgroup,
00= disabled
02 = master
0-default / preset 1,2,3
00 = load , 01 = save
1 = on , 0 = off
stereo / mic
N - value
N - value
N - value
N - value
N - value
preset 1/2/3/switch-off
status(0)
Data
DLE
ETX
03
10
03
14
Check Sum
A0
