WimTec OCEAN P7 Montage- Und Bedienungsanleitung Seite 24

EN
OCEAN P7
Commissioning
18
24 Shower panel
19
18.
Make function test: Function and program adjustments see
the following pages.
At function test pay attention that at most of operation
mode (depends on DIP switch) the shower only can be
released if the infrared sensor recognizes a user. Is a user
recognized, the vertical line in the ON/OFF symbol starts
to flash (but only in the first 30 s). If the space conditions
don´t allow that someone is inside the active area, so an
object (f.ex. hand) must be hold approx. 10 – 15 cm in front
of the room supervising sensor (below the temperature
adjustment) during the whole function text permanently.
Otherwise it can happen that the shower can not be enab-
led or it will switch off immediately.
19. Lift glass panel and hook it in final position in the front
hook. ATTENTION! Be careful not to bend or crimp any
cables or tubes.
20.
Mount protection cover.
WimTec OCEAN P7
20
