OCEAN P7
Assembly
12 13
16
13.
Hook the glas paneel at the top side of the base plate in
the retral revision hook.
14. Connect cold and warm water connection hoses.
15. Optional: Connect hand shower (use enclosed sealing).
16. Optional: Fix shower rod at the pre-mounted mounting
bracket.
17.
Establish battery supply and open shut-off valves.
Battery empty
If the battery gets empty the vertical line of the ON/OFF
symbol starts fl ashing red and the shower control stops its
function. Change the empty battery promptly.
14
17
Shower panel
15
ATTENTION!
Perform the following steps
in the order indicated!
