EN
OCEAN P7
Configuring the programs & functions
Dip-switch:
Program activation - Dip-switch 1 and 2:
Program
Semi automatic program
Fully automatic program
Manual program
Function activation - Dip-switch 3 - 6:
Dip-switch Function
3 Shut-off delay ON = 5 s / OFF
4 Warm water rinse
5 Cleaning stop
6 Stagnation rinse
1) Program or functions already configured ex factory.
Regulator controls:
I.
Interval controller
for stagnation rinse
preset to 48 h
(configurable from 3–48 h).
If the shower control is not
used for the adjusted time the
control releases a flushing to
rinse the pipes of stagnancy
water for 10 s by itself.
20 Shower panel
Dip 1
OFF
1)
ON
OFF
1)
1)
J.
Time controller
for safety flow arrest preset to
10 min (configurable from
30 s to 10 min).
Manual program mode: confi-
gurable from 10 s to 60 s.
After the configured maxi-
mum flow time has elapsed,
the water stops automatically.
WimTec OCEAN P7
Dip 2 Description
ON
Page 25
ON
Page 26
OFF
Page 27
Description
= 2 s
1)
Page 28
Page 29
Page 30
K.
Active range controller
for user detection
active range preset to 70 cm
(configurable from 30 to 70
cm).
Delimits the active range of
the infrared sensor from
30 - 70 cm.
Automatic active range
adjustment within the maxi-
mum active range.
