OCEAN P7

Technical specifications

Battery life:
Magnetic valve:
Active range:
Close-Active range:
Flushing stop:
Stagnation rinse:
Cleaning stopp:
Flow rate:
Static pressure:
Water temperature:
Flow rate:
Water inlet:
Water outlet shower:
Front plate:
Thermost handle:
Rain shower:
Dimensions in mm:
200
181
E-connection**
80-110*
18 Shower panel
5.000 flushings (approx. 1 year)
cartridge 6 V
Set to 70 cm by default (configurable from 30 - 70 cm)
4 - 5 cm
set to 10 min by default (configurable from 10 s - 10 min,
manual program: 10 s - 60 s)
for 10 s when not in use for 3–48 h
(configurable, set to 48 h by default)
10 min (switchable)
0,05 - 0,6 MPa (0,5 - 6 bar)
max. 0,8 MPa (8 bar)
max. 70 °C (max. 80 °C for max. 10 min)
max. 22 l/min at 0,3 MPa (3 bar)
R 1/2" IG
R 1/2" IT
Safety glass (ESG)
Chromed brass
Stainless steel chromed
95 8
485
½"
WimTec OCEAN P7
* At existing connections (standard dimension 153 mm)
the installation is also possible.
