N G I N E
C
OOLANT
The coolant recovery tank is located
on the inside of the door of the power
module.
1. Remove the cap on the coolant
recovery tank.
2. Add coolant to the "FULL" mark.
NOTE: Never remove the radiator cap when
the engine is hot.
O
IL
The engine must not be running
when you check and replenish the
engine oil. Refer to the Service Manual
to change the oil filter.
1. Remove the oil dipstick and check
the level indicator marks.
2. If the level is low, remove the oil filler
cap.
3. Replenish with the proper engine oil (refer to the engine service manual that came with the machine).
C A U T I O N
!
DO NOT check coolant when engine or radiator is hot; hot coolant can cause severe burns.
F
UEL
The fuel tank is located in the power module. Check the fuel
level at the gauge on top of the fuel tank.
Page 14
4 3
1 Radiator Cap
2. Coolant Recovery Tank
!
Maintenance
Figure 8: Engine
1
2
3. Oil Filler Cap
4. Oil Dipstick
Figure 9: Fuel Supply
Fuel Level
Gauge
Operator Manual
