Travel With Work Platform Elevated; Emergency Lowering - Upright 30sl Betriebsanleitung

Operation
T
R A V E L W I T H
Travel with the platform elevated ONLY on firm and level surfaces.
NOTE: The work platform will travel at reduced speed when in the elevated position.
1. Check that the route is clear of persons, obstructions, holes and drop-offs, is level and capable of sup-
porting the wheel loads.
2. Check clearances above, below and to the sides of the platform.
3. Position the Drive/Level/Lift switch to the DRIVE position.
4. Push the control lever to FORWARD or REVERSE for the desired direction of travel.
If the machine quits driving and the tilt alarm sounds, immediately lower the platform and move the
machine to a level location before re-elevating the platform.
E
M E R G E N C Y
The Emergency Lowering Switch is located on the left hand side of the chassis through the cutout in the
Control Module cover.
1. Open the Emergency Lowering Valve by pulling and holding the knob.
2. Once the platform is fully lowered, release the knob. The platform will not elevate if the Emergency Low-
ering Valve is open.
Operator Manual
W P
O R K L A T F O R M
L
O W E R I N G
060588-026 SL26/30SL
E
L E V A T E D
Page 9
