Setting the response (sun intensity)

Set the response to the sun intensity with the potentiometer and the
delivered adjustment tool. Carefully pull to remove the cover cap of
the Vestamatic Rolltec Plus G/S 500.
r The roller shutter
moves down at a
low sun intensity
(approx. 12 kLux).
o The roller shutter
moves down at a
medium sun inten-
sity (approx. 17 kLux).
l The roller shutter
moves down at a
high sun intensity
(approx. 22 kLux).
Sun response delay: 1 minute
Sun reset delay: 16 minutes
09:17 Seite 67
G/S functions
- 65 -
G

Troubleshooting

The roller shutter does not move up and down automatically.
· Is the power supply connected?
(The display flashes in case of power failure)
· Is the selector switch set to automatic (A)?
· Check, if the programmed up and down times are still stored in the
memory by shortly tapping the up or down button in automatic
mode.
· Is there a broken glass signal present?
(The display will indicate the broken glass indicator symbol)
