Note: when the voice / noise in the monitored room continues for more than 60 seconds, the monitoring radio
stop monitoring for 5 seconds, and resumes.
To set Room Monitor sensitivity
1. Press the Menu/Power button until the Room Monitor sensitivity icon flashes and the current sensitivity level is
displayed.
2. Press the "Up" or "Down" button to change the setting.
3. Choose one of the following:
a. Press the Menu/Power button to enter the new setting and proceed to other functions.
b. Press "PTT" button to save the setting and return to Standby mode.
To turn Key Tone & Roger Beep On or Off
1.Press the Menu/Power button until "P" (the Key tone& Roger beep) icon flashes on the display. The current on
or off setting is displayed.
2.Press the "UP" and "DOWN" button to turn Key tone & Roger beep on or off.
3.Choose one of the following:
a.Press the Menu/Power button to return to Standby mode.
b.Press "PTT" button to save the setting and return to Standby mode.
Dual watch receiver [dual scan]
Dual Scan is an optional feature. In dual scan, the radio looks for activity on home channel and selected dual
scan channel in the radio.
[Dual scan: 1] the user can select dual scan channel through menu. The dual scan code is the code in dual scan
channel because our radio have different code in each channel through menu setting.
[Dual scan: 2] when dual scan feature is enabled (user selected a dual scan channel through menu), a dual
icon"2CH" is displayed in LCD.
[Dual scan: 3] in dual scan mute state (no signal in home channel and dual scan channel), the home channel
with home channel's code and dual scan icon is displayed. lf home channel is active , the display do not change.
lf dual scan channel is active, the radio will display dual scan channel with dual scan channel's code and dual
scan icon. After Rx hang time, the radio will return to home channel in display.
[Dual scan: 4] the dual scan is same as normal scan except this scan does not have CSQ feature. Reference
scan description , dual scan have scan mute, scan unmute, RX hang time ,TX hang time state.

Reset function

Turn off the radio, press UP Button and Power Button at the same time to turn on the radio.

Package Contents

2 x RT45P Two Way Radio.
2 x Belt Clip
1 x Type-C Charging Cable
6 x 1000mAh AA NiMH Rechargeable Batteries
1 x RT45P User Manual
Specification Table (PMR)
GENERAL
Frequency Rang 446.00625~446.19375
MHz
Channel capacity 16 CH
Working Voltage
3.7V DC
Antenna impedance 50 Ω
Step frequency
12.5 KHz
TRANSMITTER
Output power
Adjacent channel power
TX current
Spurious radiation
modulation sensitivity
04
RECEIVER
0.5 W RF sensitivity
≥65dB Intermodulation
≤1200mA Audio output
≤7.5μW Receive current
Waiting current
8~12mv
≤0.2μV
≥55dB
>500m W
150 mA
55 mA
