TST RCCA-B / -C / -D
Gestecktes Submodule am Port
Disabled
Disabled
Disabled
IO-Link (generic Device, 2-32 Byte)
IO-Link (generic Device, 2-32 Byte)
IO-Link (generic Device, 2-32 Byte)
Digital Input
Digital Input
Digital Input
Digital Output
Digital Output
Digital Output
8.5.1 Subslot 1: IO-Link Master
8.5.1.1 Parameter
Mit diesen Parametern kann das Verhalten der I/Q Pins (Pin 2) der Subslots 2-5 (IO-Link Ports 1-4) konfiguriert
werden.
Offset [Byte] Parameter
0 IQ behaviour Port 0
1 IQ behaviour Port 1
2 IQ behaviour Port 2
3 IQ behaviour Port 3
8.5.1.2 Zyklische Eingangsdaten
Byte
Bit 7 Bit 6 Bit 5
0 - - -
8.5.1.3 Zyklische Ausgangsdaten
Byte
Bit 7 Bit 6 Bit 5
0 - - -
TST RCCA Montageanleitung
Parameter IQ Behaviour
des Kopfmoduls
Not Supported
Digital Input
Digital Output
Not Supported
Digital Input
Digital Output
Not Supported
Digital Input
Digital Output
Not Supported
Digital Input
Digital Output
Size [Bit] Options
8 0: Not supported
1: Digital input
2: Digital output
8 0: Not supported
1: Digital input
2: Digital output
8 0: Not supported
1: Digital input
2: Digital output
0: Not supported
8
1: Digital input
2: Digital output
Datenbeschreibung
Bit 4 Bit 3
I/Q Input I/Q Input
-
Value Port 3 Value Port 2
Datenbeschreibung
Bit 4 Bit 3
I/Q Output I/Q Output
-
Value Port 3 Value Port 2
I/Q (Pin 2)
no function
Input
Output
no function
Input
Output
no function
Input
Output
no function
Input
Output
Bit 2 Bit 1
I/Q Input
Value Port 1
Bit 2 Bit 1
I/Q Output
Value Port 1
40 | 76
Funktionen
C/Q (Pin 4)
no function
no function
no function
IO-Link Data
IO-Link Data
IO-Link Data
Input
Input
Input
Output
Output
Output
Bit 0
I/Q Input
Value Port 0
Bit 0
I/Q Output
Value Port 0
