5 Operating controls

5.1 Operating the touchscreen

The touchscreen is controlled using methods, similar to those used on cell phones
The following methods are used:
Tap
Tap the touchscreen to carry out simple
actions Access the menu start or stop
dispensing
Tap and hold
Many settings can be made with a so-
called "long press" without having to
go through the menu The long press is
indicated by an animation
Swipe
For dispensing durations, pressure
monitoring and other parameters, the
desired values can be set not only via a
number field, but also by "swiping"

5.2 Pressure regulator

The pressure regulator can be used to change the
pressure applied to the material being dispensed
Turn the regulator clockwise to increase the pressu-
re, turn the regulator counter-clockwise to reduce
the pressure
To prevent unintentional changes to your setting,
the regulator can be locked by pushing it towards
the dispenser
