1. When the red/white (Daytime Run Light Sense) wire
senses the vehicle's DRL is powered, the marker lights
on the plow turn on.
2. When the brown (Marker Sense) wire senses the
marker light is on from the vehicle's headlight switch
being placed into the park position, the low beam and
marker lights for the snow plow turn on.
3. When the yellow (Left Turn Sense) wire senses the
turn signal is powered, the left turn signal on the snow
plow will turn on.
4. When the gray (Right Turn Sense) wires senses the
turn signal is powered, the right turn signal on the snow
plow will turn on.
5. When the high beam button is pressed on the
transmitter, the button will illuminate blue and the high
beam lights on the plow will turn on. (Figure 1-23) Press
the button again, to turn them off. For the high beams to
operate, the vehicle will need to have the vehicle's
headlights switch placed in the park position. The high
beams can be functioned whether the transmitter is on or
off.
HIGH BEAM
BUTTON AND
INDICATOR LIGHT
Figure 1-23
NOTE: The high beam button on the transmitter has
been raised higher than the rest of the keypad to help the
operator easily locate it.
Remember to place the vehicle's headlight switch to the
OFF position when no longer using the vehicle.
NOTICE
PLACE THE VEHICLE HEADLIGHT SWITCH TO
OFF WHEN FINISHED USING THE EQUIPMENT.
LEAVING THE VEHICLE HEADLIGHT SWITCH IN
THE PARK POSITION
BATTERY.
FAILURE TO FOLLOW
PROPERTY DAMAGE.
Operation of Snow Plow Lights Using The
Energy Smart System with ProControl 2
Plus™ (For Vehicles that use a Snow Plow
Interface Module Kit)
Use the manual supplied with your vehicle's specific Snow
Plow Interface Module (SPIM) Kit.
Start/Stop Procedure for ProControl 2
Plus™ Transmitters
To prevent the ProControl 2 Plus™ transmitter from
inadvertently and accidentally being switched off the
power button is to be held approximately 2 seconds to be
turned off.

Power Saving Mode

The ProControl 2 Plus™ transmitter uses a very small
amount of electrical current anytime it is' On'. To minimize
current use when the ProControl 2 Plus™ transmitter is
inactive, the system has a 'Sleep' mode to shut itself
down. If no control function is pressed for a time period of
approximately 20 minutes, the ProControl 2 Plus™
transmitter will shut down by itself. When this happens,
the power button must be pressed and held to switch the
transmitter back "ON."
WILL DRAIN THE
COULD LEAD TO
15
