pp3
Before using the Power Probe Ill please read the instruction
carefully.
Warning!
When the PP3 switch is depressed battery current/voltage is conducted
directly to the tip which may cause sparks when contacting ground or
certain circuits Therefore
ammables such as gasoline or its vapors. The spark of an energized
Power Probe could ignite these vapors. Use the same caution as you
would when using an arc welder
The Power Probe III and
110/220-volt HOME electrical, it is only for use with 12-24-volt systems
HOOK-UP
Unroll the Power Probe cable. Connect the RED battery hook-up clip to
the POSITIVE terminal of the vehicle's battery. Connect the BLACK
battery hook-up clip to the NEGATIVE terminal Of the vehicle's battery
When the PP3 is fi rst connected to a battery (power source), it wil sound
a quick high and then ow beep and go into "Power Probe Mode (PPM)
(See Mode #1 On page 10) and the 2 bright white LEDs(dual head lights)
wil be on to illuminate the test area of the probe tip
QUICK SELF-TEST (PPM)
While the PP3 is in Power Probe Mode, press the power switch forward to
activate the tip with a positive(+) vo tage. The positive sign (+) LED should
light red and the LCD display wil read the battery (supply) voltage
tone feature is turned on, a high pitched tone will sound. Press the power
switch rearward to activate the tip with a negative (-) voltage. The negative
sign (-) LED should light green and the LCD display wil read "O O"
(ground). If the tone feature is turned on, a low pitched tone will sound
The Power Probe is now ready to use. If the indicator did not light, depress
the reset button of the circuit breaker on the right side of the housing and
try the self test again.
TURNING THE AUDIO TONE ONIOFF (PPM)
While the PP3 is in Power Probe Mode, just do a quick press Of the mode
button to toggle the tone on or off Whi e quick y pressing (a quick press
and release) the mode button, if a short high beep is heard, this means
the audio tone is turned
If a short low beep is heard, the audio tone is turned off.
the Power Probe should
the ECT 2000 are NOT
On
booklet
NOT be used around
to be used with
If the
1
fl
