Technical annex
Parameter Value
Model TTK 140 S
Dehumidification 28.5 l / 24 h
performance @ 30 °C /
80 % RH
Operating range 5 °C – 32 °C
(temperature)
Operating range 30 % – 90 % RH
(relative humidity)
Max. permissible 3.0 MPa
pressure
Suction side pressure 0.6 MPa
Discharge side pressure 1.9 MPa
Air volume flow 580 m
Mains connection 220–240 V / 50 Hz
Max. power consumption 0.6 kW
Nominal current 2.7 A
Type of protection IPX1
Water tank capacity 6 l
Refrigerant R290 (propane)
Amount of refrigerant 150 g
GWP factor 3
CO equivalent 0.00045 t
2
Sound pressure level LpA 52 dB(A)
(1 m; complies with
DIN 45635-01-KL3)
Dimensions 400 x 400 x 605 mm
(length x width x height)
Minimum distance to
walls or other objects
top (A): 50 cm
rear (B): 50 cm
sides (C): 50 cm
front (D): 50 cm
Weight 27.5 kg
B - 44
TTK 170 S
35.5 l / 24 h
5 °C – 32 °C
30 % – 90 % RH
3.0 MPa
0.6 MPa
2.1 MPa
3 3
/h 580 m
220–240 V / 50 Hz
0.6 kW
2.8 A
IPX1
6 l
R290 (propane)
150 g
3
0.00045 t
52 dB(A)
540 x 490 x 963 mm
50 cm
50 cm
50 cm
50 cm
32 kg
dehumidifier TTK 140 S / TTK 170 S / TTK 350 S / TTK 650 S
Technical data
TTK 350 S
63.5 l / 24 h
5 °C – 32 °C
30 % – 90 % RH
3.0 MPa
0.6 MPa
2.2 MPa
3
/h 490 m /h
220–240 V / 50 Hz
1.4 kW
6.1 A
IPX1
6 l
R454C (F-Gas)
650 g
146
0.09490 t
54 dB(A)
530 x 500 x 965 mm
50 cm
50 cm
50 cm
50 cm
39 kg
TTK 650 S
88 l / 24 h
5 °C – 32 °C
30 % – 90 % RH
3.0 MPa
0.6 MPa
2.8 MPa
3
925 m /h
220-240 V / ~ 50 Hz
2.1 kW
9.5 A
IPX1
-
R454C (F-Gas)
1050 g
146
0.15 t
56 dB(A)
616 x 511 x 1022 mm
50 cm
50 cm
50 cm
50 cm
52 kg
