Symbology
SYMBOLOGY
REFER TO INSTRUCTION
MANUAL/BOOKLET
WEAR EYE PROTECTION
VOLTS
DIRECT CURRENT
n
xxx/min
NO LOAD SPEED
0
CE MARK
CANADIAN - UNITED STATES
UNDERWRITERS LABORATORY
FCC
FEDERAL COMMUNICATIONS
COMMISSION
JAPAN ELECTRICAL SAFETY
TÜV RHEINLAND
DOUBLE INSULATION
BACK FEED PROTECTION
PROPERLY RECYCLE BATTERY
Li-ion
DO NOT THROW IN GARBAGE
BC
CALIFORNIA - TITLE 20
COMPLIANT
UKCA (UK CONFORMITY
ASSESSED) MARKING
ZCTCO861CE Rev C
EN
EN
Battery Pack
Specifications
DO NOT USE CTB6172
Type
CTB8174 ............................................ Lithium-Ion
Voltage
CTB8174 .............................14.4V (3.6 V x 4 cells)
Weight
CTB8174 ......................................... 0.6 lbs (.3 kg)
Charge Time
CTB8174 ..................................................~70 min
Life
CTB8174 ............................................ 1000 cycles
Note: 1 cycle=1 charge and 1 discharge
Capacity
CTB8174 ...................................................2.5 A•H
Discharge Temperature Range
CTB8174 ................... -4°F(-20°C) to 140°F(60°C)
Battery Charger
Specifications
Input
CTC772A ..................................120 VAC, 50/60 Hz
CTC772A/CTCA772A/CTCEU772A/CTCJ772A ........
......................................... 220-240VAC, 50/60 Hz
CTCJ772A ................................ 100VAC, 50/60 Hz
Output
All Models .....................................................3.0 A
Weight
All Models ................................... 1.0 lbs (0.47 kg)
Charging Temperature Range
CTB8174 ...................... 32°F(0°C) to 113°F(45°C)
DO NOT BLOCK VENT OPENINGS!
Application
The Snap-on CTCO861 Cordless Cut Off Tool is
ideal for many automotive and industrial cutting
applications. By using various abrasive cutting
wheels rated at maximum tool speed or higher,
the cutter can be used to cut through piping,
sheet metal or bolts. The detented safety guard
rotates to any safe and convenient position.
9
RCM (REGULATORY
COMPLIANCE MARK)
(09/24)
