Next Level Racing F-GT PRO NLR-R005 Bedienungsanleitung Seite 9

75 mm
07
Loosen or remove the Bolts indicated above and change the Shifter & Handbrake Plate Assembly to
your desired Height, Angle and Position. Retighten or reinstall the Bolts to lock in place.
SHIFTER & HANDBRAKE PLATE LEVELING
If Shifter & Handbrake Plate is tilting away from cockpit, loosen all 4 Shifter Arm mounting Bolts, pull
08
upwards on Shifter Arm until Shifter Plate is level. Tighten Shifter Arm mounting Bolts whilst holding
upwards tension.
ADJUSTMENTS
53 °
9
Video Instruction: bit.ly/nlrbuild
PARTS:
• • NIL
125 mm
PARTS:
• • NIL
