3 ▲+▼
4 ▼
5 SET
6 SET+RST
parameters. If no key is pressed within 20 seconds, the
controller will automatically exit the parameter setting state
and will not save the modified parameters. (When the
parameter setting state, the system runs according to the
original parameters)
After holding the ▲▼ key at the same time, the thermostat is
Parameter powered on, and "rE" is displayed after three seconds, and the
adjustment newly adjusted manufacturer parameter value (the
parameter adjusted by " ▲+▼+RST") takes effect, and
returns to normal operation after three seconds.
Check the 1. Press the ▼ key once to display t1, and then press the ▼
room key to display the room temperature.2. Press the ▼ key once
temperature to display t2, and then press the ▼ key to display the flow rate
flow value 1 (single for liter: L).3. Press the ▼ key once to display t3, and
(red light D1 then press the ▼ key to display flow rate 2 (single for liter:
flashing) L).4. No button is pressed, and the water temperature is
restored after six seconds.
Note: Live traffic L = flow frequency HZ/flow coefficient.
Press the SET key while the thermostat is working properly:
1. The thermostat works in the constant temperature mode of
the intelligent thermostat, and the panel displays the
parameter value of F0 (set temperature).
Quick adjust 2. The thermostat works in intelligent mode, and the panel
displays the parameter value of F1 (temperature
difference value). Panel D1 now flashes, indicating that the
controller is now in the setting state for the parameter.
Press the ▲▼ key to modify the setting, then press the SET
key or press it without a key for 20 seconds
then do not save and exit. If you press the RST key, the disk is
saved and exited,and the new parameter takes effect.
During 5 minutes of powering on, press the "SET key" and
"RST key" at the same time for 10 seconds to enter the
self-test mode, and perform the following logic in turn:
1. Display the program version.
2. Display -11.1 ~-22.2 All indicator lights are on, and the
Self-test compressor relay is closed and disconnected once.
mode 3. Display -33.3 All indicator lights are on, and the solenoid
valve relay is closed.
4. Display 444 All indicator lights are off, and the solenoid
valve relay is disconnected.
5. Display 555~666 All indicator lights are off, and the alarm
relay is closed and disconnected once.
6. Display 777~888 All indicator lights are off, and the buzzer
rings once. 7. Exit the self-test mode.
