13 Maintenance and servicing
13.5 Tensioning/loosening the engine V-belt
Engine V-belt
When the engine cover is raised, the engine V-belt is centrally located in
the machine. Access is provided by removing the tread plate. To tension/
replace the belt, the screw connection of the tensioner must be loose-
ned/tightened on the right in the direction of travel. The belt is placed
or removed via the belt pulleys as shown in the illustration opposite.
Install the new belt in the appropriate order.
NOTICE
44
(Fig. 21 - Tensioning / loosening the engine V-belt)
Apply pressure to the V-belt with two fingers. If the
preload is correct, the belt can be pressed down by
only 10 mm.
If the V-belt is new, then by only approx. 5 mm.
