TWIN CYLINDER AIR COMPRESSOR - PPKOD 5010 A1
1. Introduction
Congratulations on the purchase of your new device. You have thus chosen a high-quality product. The manual is part of this product.
It contains important instructions for safety, use and disposal. Familiarise yourself with all operating and safety instructions before using
the product. Only use the product as described and for the specified areas of application. Hand over all documents when passing the
product on to third parties.
1.1 Intended use
The compressor is used to operate pneumatic tools in the home workshop. It is designed to draw in and compress clean, dust-free,
dry and uncontaminated ambient air. The ambient air must not contain any aggressive or flammable admixtures. The compressor may
only be used in closed spaces with sufficient ventilation. Pneumatic tools can be connected to the compressor and used for blowing,
screwing, tacking and varnishing. This compressor is also suitable for devices with higher power requirements such as compressed
air impact wrenches or compressed air chisel hammers. Read the relevant manual for the correct use of these pneumatic tools. The
compressor and the connected pneumatic tools may only be operated by a trained person. For persons with limited physical, sensory
or mental abilities as well as children and adolescents, operating the compressor and connected pneumatic tools is prohibited. Intended
use also includes compliance with all the information in this manual.
Any other use or modification of the products is considered improper and involves considerable risk of accidents. We accept no liability
for damage resulting from improper use. The products are intended for private use only and may not be used commercially or indus-
trially.
1.2 Scope of delivery
1 Compressor
2x Wheel
2x Wheel cover
2x Support stand
2x Air filter
Assembly material:
2x Flange nut
2x Nut
2x Phillips screw
2x Washer
2x Hexagon head screws M8x25
2x Hexagon head screws M8x12
1x Bottle of compressor oil (250ml)
1x Manual
6
GB/IE/NI/CY/MT
1.3 Features
1 Transport handle
2 On/off switch
3 Oil sealing plug
4 Air filter
5 Pressure vessel (boiler)
6 Wheel cover
7 Wheels
8 Drain plug (for condensation)
9 Support stands
Pressure gauge (tank pressure)
10
Safety valve
11
Quick coupling (tank pressure)
12
Pressure regulator
13
Quick coupling (regulated pressure)
14
Pressure gauge (regulated pressure)
15
Oil drain plug / oil level indicator
16
Phillips screw
17
Washers
18
Flange nuts
19
Hexagon head screws M8x25
20
Nuts
21
Bottle of compressor oil
22
Hexagon head screws M8x12
23
Overload switch
24
