EuroLite LED PIXEL MATRIX BAR 10 Bedienungsanleitung Seite 39

42-Channel-Mode
Channel Value
1 000 – 255
2 000 – 255
3 000 – 255
4 000 – 255
.
.
.
37 000 – 255
38 000 – 255
39 000 – 255
40 000 – 255
41 000 – 255
42 000 – 255
Strobe Table
Value Function
000 – 010 No function
011 – 040 Strobe effect 1, with increasing speed
041 – 070 Strobe effect 2, with increasing speed
071 – 100 Strobe effect 3, with increasing speed
101 – 127 Strobe effect 4, with increasing speed
128 – 255 Strobe effect 5, with increasing speed
Animated Macro Table
Value Function
000 – 004 No function
005 – 009 Animated macro 1
010 – 014 Animated macro 2
015 – 019 Animated macro 3
.
.
.
.
.
.
245 – 249 Animated macro 49
250 – 255 Animated macro 50
Static Pattern Table
Value Function
000 No function
001 – 003 Static pattern 1
004 – 006 Static pattern 2
007 – 009 Static pattern 3
.
.
.
.
.
.
250 – 252 Static pattern 84
253 – 255 Static pattern 85
Red 1
Green 1
Blue 1
Warm white 1
.
.
.
.
.
Red 10
Green 10
Blue 10
Warm white 10
Master dimmer 0 – 100%
Strobe effect (see Strobe Table)
Function
Increasing brightness 0 – 100%
39/44
00159459, Version 1.0
