EuroLite LED PIXEL MATRIX BAR 10 Bedienungsanleitung Seite 38

10-Channel-Mode
Channel Value
1 000 – 255
2 000 – 255
3 000 – 255
4 000 – 255
5 000 – 255
6 000 – 255
7 000 – 255
8 000 – 255
9 000 – 255
000 – 127
10
128 – 255
15-Channel-Mode
Channel Value
1 000 – 255
2 000 – 255
3 000 – 255
4 000 – 255
5 000 – 255
6 000 – 255
000 – 127
7
128 – 255
8 000 – 255
9 000 – 255
000 – 255
10
000 – 127
11
128 – 255
12 000 – 255
13 000 – 255
000 – 255
14
15 000 – 255
40-Channel-Mode
Channel Value
1 000 – 255
2 000 – 255
3 000 – 255
4 000 – 255
.
.
.
37 000 – 255
38 000 – 255
39 000 – 255
40 000 – 255
Red increasing brightness 0 – 100%
Green increasing brightness 0 – 100%
Blue increasing brightness 0 – 100%
Warm white increasing brightness 0 – 100%
Master dimmer 0 – 100%
Strobe effect, (see Strobe Table)
Static macros (see Static Pattern Table)
Animated macros (see Animated Macros Table)
Animated macros to sound (see Animated Macros Table)
Animated macros forward, with decreasing speed
Animated macros backward, with increasing speed
Red increasing brightness 0 – 100%
Green increasing brightness 0 – 100%
Blue increasing brightness 0 – 100%
Warm white increasing brightness 0 – 100%
Master dimmer 0 – 100%
Strobe effect, (see Strobe Table)
Fading colors off
Fading colors on
Static macros (see Static Pattern Table)
Animated macros (see Animated Macros Table)
Animated macros to sound (see Animated Macros Table)
Animated macros forward, with decreasing speed
Animated macros backward, with increasing speed
Red background color
Green background color
Blue background color
Warm white background color
Red 1
Green 1
Blue 1
Warm white 1
.
.
.
.
.
Red 10
Green 10
Blue 10
Warm white 10
Function
Function
Function
Increasing brightness 0 – 100%
38/44
00159459, Version 1.0
