Mantis Tiller assembly
KEY QTY
1 1 400257
2 1 400255
6 2 400224
7 1 400620
8 1 148
12 1 910502
13 2 478
20 1 465
21 1 400911
22* 1 468
23 1 466
24 1 436
25 1 437A
26 4 651
27 1 423
28 2 425
29 1 424
30 1 422
31 1 426
32 1 428
33 1 429
MATERIAL
TRIGGER HANDLE
ASSM. RH
HANDLE ASSM. LH
LOWER HANDLE -
FOLD DOWN
LABEL
HANDLE BRACE
10-32 X 3/4 -
FLANGED BOLT
THROTTLE CLIP
FENDER GUARD
ENGINE ASSY - 25CC
4 STROKE
DRIVE SHAFT
WORM GEAR
HOUSING
GASKET
HOUSING COVER
RD. HD. SELF
TAPPING SCREW
ROLLER BEARING
WORM BEARING RACE
WORM THRUST
BEARING
WORM SHAFT
WORM DISK
RETAINING RING
WORM GEAR
KEY QTY
34 1 431
35 2 430
36 2 432
37 2 434
38 2 435
39 1 438RA
40 1 438LA
41 2 418-1
42 1 400133
43 1 400130
44 1 400609
45 1 458
46 1 4058
47 2 410
48 4 972
49 2 470
50 2 140
51 2 377
52 2 400509
53 2 400523
54 2 400230
55 1 400010
56 1 400132
57 1 400131
60 4 400511
* Also in Key no. 55
MATERIAL
TINE SHAFT
WORM GEAR THRUST
WASHER
WORM GEAR BEARING
BEARING
BEARING SEAL RETAINER
TINE ASSY - RT
TINE ASSY - LT
TINE RETAINING HAIR PIN
CARRYING HANDLE
ENGINE FLANGE
TINE LABEL
ROLLER BEARING
MANTIS LABEL
CAP SCREW 1/4-20 X 1" LG.
LOCK NUT 1/4 - 20
1/4-20 X 3.25 BOLT
BOLT 1/4 - 20 X 3/8" LG.
HANDLE CLAMP
BOLT
KNOB
PLUG
TRANSMISSION ASSEMBLY
BEARING
CLUTCH DRUM
M6 X 12 - FLANGED BOLT
