• Do not load the machine so much that it comes to
a standstill.
• Always press the workpiece firmly against the
working plate.
• Never remove loose splinters, chips or jammed
wood pieces from the running saw blade.
• Switch off the machine to rectify any faults on the
blocked tool attachment. Pull out the mains plug.
Remove the blockage. Attention! Danger of injury
due to saw blade! Wear protective gloves! Perform
a test run without a workpiece. Make sure that no
unusual noises or vibrations occur. If this is the case,
switch the device off and contact the manufacturer.
• Only carry out modifications, adjustments, meas-
urements and cleaning work when the motor is
switched off. Pull out the mains plug.
• Before switching on, make sure that keys and ad-
justing tools are removed.
• Switch off the motor and pull out the mains plug
when leaving the work station.
• Electrical installation, repairs and maintenance
work may only be carried out by specialists.
• All protective and safety equipment must be reas-
sembled immediately after repair or when mainte-
nance is completed.
• The safety, operating and maintenance informa-
tion of the manufacturer, as well as the dimensions
specified in the technical data, must be observed.
• The relevant accident prevention regulations and
the other generally accepted safety rules must be
observed.
• The saw is only intended for installation indoors.
• Workpieces that are smaller than the saw blade
guard can cause injuries to the hands and fingers.
Use a suitable aid!
• Avoid cramped hand positions when guiding the
workpiece and positions in which the hand would
slip directly into the saw blade.
• Always insert the saw blade so that the teeth point
down towards the saw table.
• Always set the correct blade tension in order to
avoid breaking the saw blades.
• Use extra care when cutting material with irregular
cutting profiles.
• When withdrawing the workpiece, teeth can get
caught in the kerf, especially if the shavings block
the kerf. In this case you should switch off the saw,
pull out the mains plug, open the kerf with a wedge
and remove the workpiece.
• Never leave the work station without setting down
the saw beforehand. Wait until the saw has come
to a standstill.
• Do not place, glue, or assemble any parts on the
work table while the saw is running.
• Do not switch on the saw until the work table is
cleared of material residues and tools. Only leave
the workpiece to be machined and any work aids
(wedges) on the workbench.
24 | GB
www.scheppach.com
• Always wear safety goggles.
• Keep fingers at a safe distance from the saw blade.
• Guide the workpiece securely and firmly and do not
let it loose at any point.
• Never leave the work station without setting down
the saw beforehand.
• Do not let your familiarity with the saw lead you to
carelessness. Carelessness can lead to serious in-
juries in a split second.
Store the safety instructions safely.
6. Technical data
Mains voltage ................................ 220-240 V~/50 Hz
Power consumption ............................... 80 Watt (S1*)
....................................................120 Watt (S6 30%**)
Stroke rate ............................................ 500-1700 rpm
Lifting movement ..............................................12 mm
Base .................................................... 630 x 295 mm
Tilting table ....................................0° to 45° to the left
Table size ............................................. 415 x 255 mm
Saw blade length approx. ...............................134 mm
Swing ............................................................. 406 mm
Cutting height max. at 0° ................................. 50 mm
Cutting height max. at 45° ............................... 22 mm
Weight ............................................................. 12.7 kg
*Operating mode S1:
Continuous operation at constant load
**Operating mode S6 30%:
Continuous duty with intermittent loading (operating
time 10 mins). In order avoid impermissible overheat-
ing of the motor, the motor should be driven for only
30% of the operating time with the stipulated nominal
power and must then continue to run with no load for
the remaining 70% of the operating time.
Device emissions values
Noise
The noise levels have been determined in accord-
ance with EN 61029.
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Sound pressure level L ........................... 66,9 dB(A)
pA
Uncertainty K .................................................... 3 dB
pA
Sound power level LWA ............................ 79,9 dB(A)
Uncertainty K ................................................... 3 dB
WA
Vibration emission value
• The specified vibration emission value has been
measured according to a standardised testing pro-
cedure and can be used for comparison of one
electric tool with another;
• The specified vibration emission value can also be
used for an initial assessment of the (vibration) load.
• The vibration emission value can vary from the
specified value during the actual use of the elec-
tric tool, depending on the type and the manner in
which the electric tool is used;
A warning:
• It is necessary to determine the safety measures
for the protection of the operator based on an as-
sessment of the vibration load during the actual
conditions of use (In doing so, all parts of the op-
erating cycle must be taken into account such as
times in which the electric tool is switched off or
times in which it is switched on, but is not running
under a load).
The stipulated values are emission values and so do
not necessarily represent safe work station values. Al-
though there is a correlation between emission levels
and exposure levels, it is not possible to reliably deter-
mine whether additional precautionary measures will
be required or not based on this.
Factors that could influence the emissions level pre-
sent at any given time at the work station include the
duration of exposure, the nature of the working area,
other noise sources etc. e.g. the number of machines
and neighbouring processes.
The permitted workstation values can also vary from
country to country. However, this information should
enable the operator to better evaluate the hazards
and risks.
Limit the noise level to a minimum!
• Only use faultless devices.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
• Switch the device off if it is not in use.
Suitable saw blades
All industry-standard saw blades with a minimum
length of 127 mm with and without a pin may be used.
7. Before commissioning
7.1 Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage.
• If possible, keep the packaging until the expiry of
the warranty period.
www.scheppach.com
WARNING
The device and the packaging are not children's
toys! Do not let children play with plastic bags,
films or small parts! There is a danger of choking
or suffocating!
7.2 General notes
• Prior to commissioning, all covers and safety de-
vices must be mounted correctly.
• The saw blade must be able to run freely.
• In case of previously machined wood, be aware of
any foreign bodies, such as nails or screws, etc.
• Before pressing the on/off switch, make sure that
the saw blade is correctly fitted, and that moving
parts run smoothly.
• Before connecting the machine, make certain that
the data on the type plate matches with the mains
power data.
• Only connect the machine to a correctly installed
protective contact socket, with fuse protection of at
least 10 A.
7.3 Install the scroll saw on the workbench
You require the following for assembly:
• M8 hexagonal bolt (4x)
• M8 hexagonal nut (4x)
• Washer Ø 8.4 mm (8x)
(not included in the scope of delivery)
The length of the screws to be used vary depending
on the thickness of the tabletop.
WARNING
Danger of injury! Disconnect the mains plug on the
scroll saw before all assembly work.
1. Mount the scroll saw on a solid wooden work-
bench. This way, a high noise level due to vibra-
tions can be avoided.
2. Mark the drill holes (see fig. 5.2).
3. Drill the 4 holes (diameter 8 mm) into the workbench.
4. Screw the scroll saw onto the workbench with the
hexagonal bolt (E) through the assembly points
(fig. 3 pos. 19) in the following sequence (fig. 5.1):
D Hexagonal nut
C Washer
A Scroll saw
B Workbench
C Washer
E Hexagonal bolt
5. Tighten the hexagonal nuts (D).
8. Layout
WARNING
Danger of injury! Disconnect the mains plug on the
scroll saw before all assembly work.
