Caution! Do not open the battery compartment
frequently.
SV
1
Turn the product upside-down. (Figure 18)
2
Remove the 4 screws that holds the battery
NO
compartment with a screwdriver.
3
PL
Disconnect the plug.
4
Take out the battery pack and replace it with the
DE
new one.
8

Troubleshooting

FI
8.1

Error codes

FR

Fault code

A1
NL
E1
E2
E3
E4
26

Possible cause

The product is outside the charging
station.
The product is outside the working
area.
The wheel motor is blocked
The blade disc blocked
The obstruction sensors trigger are
not activated.
Task
● Put back the product on the charging station and
make sure that the electrodes are correctly connected.
● Do a check in the app if the product is within its
designated working area.
● Put it back to the working area.
● If the limit line line is not clear, put magnetic strips so
that the product stays inside the limit line.
● Stop the product and put it to an area without
obstacles.
● To start push the "START" button then the "OK" button.
● If the fault message continues, stop the product and
turn it upside down. Do a check if there is a blockage
in the wheels that prevents them to rotate.
● Remove the blockage and turn the product upright.
● To start push the "START" button then the "OK" button.
● Stop the product.
● Turn it upside down. Do a check if there is blockage in
the blade disc that prevents the rotation.
● Turn the product upright and put it on an area with
short grass or adjust the cutting height.
● To start push the "START" button then the "OK" button.
● Stop the product and put it to an area without
obstacles.
● To start push the "START" button then the "OK" button.
