If the connection to the Wi-fi is successful the
EN
Wi-Fi icon on the product will light up.
SV

3.5 To enter the PIN code

1
Put the product into the charging station. Make
NO
sure that the electrodes of the product are
correctly connected to the charging station. The
green indicator lamp of the charging station will
PL
start to flash to indicate that the charging is in
progress. (Figure 11)
DE
2
Enter the default PIN code "0000" on the control
panel. Push the "OK" button to register each digit.
The digit "0" will flash on the display. (Figure12)
FI
Note! If the wrong PIN code is entered 10 times, the
screen will show "LOCK" and the product stop. Wait 10
FR
minutes to enter the password again.
3
Push the "OK" button to complete the setting
NL
process.
4

Operation

Warning! Do a check of the lawn for obstacles,
stones, or other debris that can get caught or thrown by
the product during operation. (Figure 13)
Warning! Stop and disconnect the product from
the power supply and make sure that the blades have
completely stopped before you examine, clear blockage,
or do maintenance to the product.
Warning! The product operation must be moni-
tored if there are children or pets in the mowing area.
Note! Do not let the product operate slopes steeper than
42% (22°). (Figure 14)
● Do not operate the product at night. Dark
environments can have negative effect on the function
of the wide-angle camera to accurately recognize
obstacles.
● Make sure that there are no objects for example
stones, branches, tools or toys on the lawn. The blades
can be damaged if they hits an object.
● If there are too many obstacles in your lawn, consider
setting up a no-go zones around them or remove
some of the obstacles to improve the efficiency of the
product.
● The obstacle avoidance functions increases product
performance and personal safety.
22
● Do not use the product at the same time as a pop-up
sprinkler. Use the schedule function so the product
and pop-up sprinkler do not operate at the same time.
● Do not let the product operate when there is standing
water in the work area. For example, when heavy rain
forms pools of water.
4.1

To charge the product

Warning! Do not charge the product if the tem-
perature is above 40°C or below 5°C.
Warning! Stop the charging if an unusual smell or
sound comes up.
Note! The life of the battery depends on how often the
product is used and the total working hours. When the
operation time is significantly shorter than usual per full
charge or the lawn is not well-cut, replace the battery.
● Longer life and better performance can be obtained if
the battery pack is charged when the air temperature
is between 18°C and 25°C.
● The Battery pack gives its best performance when it is
operated at normal room temperature (20 °C ± 5 °C)
1
Put the product into the charging station. Make
sure that the electrodes of the product are
correctly connected to the charging station.
2
Refer to "4.1.1 Status indicator guide of the charging
station" on page 22
4.1.1 Status indicator guide of the charging
station
Indicator Description
● The charging station is
connected to the power supply.
Steady green
● The battery is fully charged.
Flashing green The battery is charging.
No indicator ● There is no power supply to the
product.
● Make sure that the power cable
and the adapter is correctly
connected to the charging
station.
Note! If the indicator light do not
turn on even if the there is power
supplied, refer to an approved
service center.
