E. Make sure that the QR-code on the charging
station is always clean. (Figure 4)
F. The charging station can be installed inside the
lawn area, in the corner or along side of the edge
of the lawn. The area must be at least 25 cm away
from the nearest limit line with no obstacles within
2 m at the front. The distance from the front of the
charging station to the limit line should not be less
than 2m. (Figure 4)
2
Connect the charger to the power supply.
Caution! Put the power cable outside the mowing
area. If it is necessary to put the power cable in the
mowing area, bury it.
3
Install the power adapter on a wall, at least 30 cm
from the ground.
4
Connect the power cable to the charging station
and to the power adapter.
5
Connect the power adapter to a power outlet.

3.2 To install the magnetic strips

The magnetic strip is used to create a virtual border
when the limit line is not easy to locate.
For example: (Figure 5)
• There is no border or limit line between your lawn
and the surrounding lawn.
• To protect flower beds.
• To create a border near muddy pits or puddles
• To create a border from sloped higher than 42%
Note! Do not bury the magnetic strips.
1
Put the magnetic strip on the ground and safety it
with the ground pegs every 0.5 meters.
2
Connect 2 strip together with a magnetic strip
connector if the magnetic strip is not long enough.
(Figure 6–7)
Note! The included magnetic strip is 5 meters long.

3.3 To install the magnetic tags

The magnetic tags are used when there is more than 1
working area.
● Make sure that the pathway is not longer than 5
meters.
● Make sure there are no obstacles on the pathway.
Note! If the number of the working zones is more than 2
more tags are necessary.
1
Position the magnetic tags on both side of the
pathway to create a way for the product to cross to
different working areas. (Figure 9)
Note! The arrow on the magnetic tags must point to each
other.
2
Safety the magnetic tags on the pathway with the
included pegs.
3
Keep a distance of 30±5 cm from the limit line for
the tags and make sure there are no obstacles
within a 1.5 meter radius.

3.4 To install the Robotic Mower app

Note! Make sure that the product is on the charging
station.
Note! Make sure the registration process is completed
before you log in.
1
Scan the QR-code to download the app.
(Figure 10)
2
If you cannot scan the QR- code, go to the Google
Play Store (Android) or the Apple App Store (iOS)
and look for "Robotic Mower".
3
Start the bluetooth and the Wi-fi connection on
your device.
4
Follow the instruction in the application to sign up
and log in.
5
Scan the QR-code (attached on the product) to
register your product.
6
After pairing the product with the app, enter the
default password "0000".
Note! The PIN-code can be changed in the Robotic
Mower app.
7
Configure your Wi-fi connection for the product.
Note! The product must be connected in the same Wi-fi
as the device.
Note! The product can be connected to a hotspot
network.
