RDM Isolator — Information for Use
6
Use cases
A DMX booster/refresher is typically required when distances of
more than 300 meters are required.
DMX source
A DMX booster is also required after 32 passive (non-RDM non-
boosting) DMX fixtures.
DMX source
Please note:
All RDM fixtures must be placed after the last RDM
Isolator. DMX Auto addressing fixtures have compatibility
issues with RDM. Place DMX Auto Addressing fixtures and
DMX/RDM fixtures in separate DMX lines.
| Use cases
DMX out
max. 300 m (DMX)
max. 200 m (e:pix)
#1
DMX out
#33
RDM Isolator
In
Out
max. 300 m (DMX)
max. 200 m (e:pix)
Non-boosting, non-RDM devices
#2
#31
In
Out
RDM Isolator
#34
#35
DMX/RDM devices
DMX in
#32
7 / 16
