PRODUCT PARTS
EN
Newborn inlay (1)
(separately available)
Size indicator (2)
Load leg (3)
ISOFIX-Release buttons (4)
ISOFIX-Locking arms (5)
ISOFIX-Anchorage points (6)
ISOFIX-Indicators (7)
Load leg adjustment button (8)
Load leg indicators (9)
Seat locking indicators (10)
DIFFERENT USES OF THE SEAT
61 – 105 cm,
approx. 3 M – approx. 4 Y
max. 20 kg
A Newborn inlay (1) can be purchased as a separate accessory and allows for
usage of Sirona Gi i-Size from 40 cm on. It should be removed if your child is
taller than 60 cm. The Size indicator (2) shows the minimum size your child
must reach before it is permitted to convert the seat for forward-facing use.
THE CORRECT POSITION IN THE VEHICLE
This is an i-Size Enhanced Child Restraint System. It is approved according
to UN Regulation No. R129/03, for use in i-Size compatible vehicle seating
positions as indicated by vehicle manufacturers in their vehicle user manuals. If
your vehicle does not have an i-Size seating position, please check the vehicle
Type List. You can obtain the most up-to-date version of the Type List from
go.cybex-online.com/sirona-gi-isize-car-compatibility.
6
Headrest (11)
Headrest adjustment handle (12)
Position adjustment handle (13)
Belt adjustment button (14)
Shoulder belt (15)
Belt buckle (16)
Buckle tongues (17)
Lap belts (18)
Central adjustment belt (19)
Seat rotation handles (20)
76 – 105 cm,
> 15 M – approx. 4 Y
max. 20 kg
INSTALLATION IN THE VEHICLE
Always ensure that...
• the backrests in the vehicle are locked in their upright position.
• when installing the car seat on the front passenger seat, adjust the vehicle
seat as far back as possible.
1. Fold out the Load leg (3) until it locks into its foremost position.
2. Release the ISOFIX-Release buttons (4) to extend the ISOFIX-Locking
arms (5) on both sides.
The ISOFIX-Release buttons can both be released independently allowing
��
the ISOFIX-Locking arms to be adjusted independently.
3. Push the ISOFIX-Locking arms (5) out of the car seat to their furthest
extent.
4. Place the car seat on an appropriate seat in the vehicle.
5. Push the ISOFIX-Locking arms (5) into the ISOFIX-Anchorage points
(6) until these lock into place with an audible "CLICK". The two ISOFIX-
Indicators (7) will switch from RED to GREEN.
6. Ensure the car seat is secure by trying to pull it out of the ISOFIX-
Anchorage points (6).
7. Push the car seat towards the backrest of the vehicle seat until it is fully
aligned with the backrest.
Moving the car seat from side to side will also brace it against the vehicle
��
backrest.
8. Press the Load leg adjustment button (8) and extend the load leg until it
touches the vehicle floor.
9. Pull the Load leg (3) out to the next locking position to ensure optimal force
transmission.
10. The Load leg indicator (9) switches to GREEN when the load leg is
correctly positioned on the vehicle floor.
REMOVAL FROM THE VEHICLE
1. Unlock the ISOFIX-Locking arms (5) on both sides by pressing the ISOFIX-
Release buttons (4) and at the same time pulling them back.
2. Pull out the car seat from the ISOFIX-Anchorage points (6).
3. Remove the car seat and slide the ISOFIX-Locking arms (5) completely
back into their transport positions.
4. Push the Load leg (3) back into its original position and then fold it in to
save space.
