16 | English
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may result
in electric shock, fire and/or serious
injury.
Intended Use
The power tool is intended for sawing and sepa-
rating wooden materials, plastic, plaster, non-
ferrous metals and fasteners (e.g. nails and
clamps) as well as for working on soft wall tiles
and for dry grinding of small surfaces. It is espe-
cially suitable for working close to edges and for
flush cutting. The power tool must be used with
Bosch accessories only.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 On/Off switch
2 Thumbwheel for orbit frequency preselection
3 Vacuum connection
4 Vacuum hose*
5 Venting slots
6 Tool holder
7 Plunge saw blade
8 Clamping bolt with washer
9 Allen key
10 Sanding plate
11 Sanding sheet
12 Segment saw blade
*The accessories illustrated or described are not in-
cluded as standard delivery.
2 609 000 229 | (2.7.08)
Technical Data
Multi-function tool
Article number
Preselection of orbital
stroke rate
Rated power input
Output power
No-load speed n
0
Oscillation angle,
left/right
Weight according to
EPTA-Procedure
01/2003
Protection class
The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific
countries, these values can vary.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
Noise/Vibration Information
Measured values determined according to
EN 60745.
Typically the A-weighted noise levels of the prod-
uct are: Sound pressure level 85 dB(A); Sound
power level 96 dB(A). Uncertainty K <1.5 dB.
Wear hearing protection!
Vibration total values (triax vector sum) deter-
mined according to EN 60745:
Sanding: Vibration emission value a
Uncertainty K<2.0 m/s
Cutting with plunge cut saw blade: Vibration
emission value a
=9.9 m/s
h
2
K<1.5 m/s
,
Cutting with segmential saw blade: Vibration
emission value a
=5.0 m/s
h
2
K<1.5 m/s
.
The vibration emission level given in this informa-
tion sheet has been measured in accordance
with a standardised test given in EN 60745 and
PMF 180 E
3 603 A00 0..
W
W
15000 – 21000
rpm
°
kg
=6.4 m/s
h
2
,
2
, Uncertainty
2
, Uncertainty
Bosch Power Tools
180
74
1.4
1.2
/ II
2
,
