8.
Use of the microscope
8.1
Switching on the microscope
8.1.1
OS-A1
Operate on the main switch ① placed in the rear side of the mi-
croscope, moving the selector on "I". (Fig. 5)
8.1.2
OS-A2 / OS-A3
1. Operate on the main switch/light intensity dial ② placed on
the left side of the microscope, to turn on transmitted light.
(Fig. 6)
2. Operate on the main switch/light intensity dial ③ placed on
the right side of the microscope, to turn on incident light.
8.1.3
OS-B2 / OS-B3
Operate on the main switch ④ placed in the rear side of the mi-
croscope, moving the selector on "I". (Fig. 7)
8.1.4
OS-C3
Operate on the main switch ⑤ placed on the right side of the
microscope, moving the selector on "I". (Fig. 8)
All manuals and user guides at all-guides.com
Page 11
①
②
④
F ig. 5
F
ig. 5
③
F ig. 6
F
ig. 6
F ig. 7
F
ig. 7
⑤
F ig. 8
F
ig. 8
