reducer to set the working pressure.
• RECOIL FORCES! At high working pressures, re-
coil forces can occur which can, under certain cir-
cumstances, lead to hazards due to continuous
loading.
• RISK OF INJURY! MISUSE! Never point the device
at people and / or animals.
• RISK OF INJURY! Never use oxygen or other flam-
mable gases as a source of energy.
• RISK OF INJURY! First disconnect the hose
from the compressed air source and only then
remove the supply hose from the device. In this
way you avoid uncontrolled whirling or recoil of the
supply hose.
• Use suitable body protection equipment for
your personal protection.
• Keep children and other people away while using
the tool. Distractions may cause you to lose control
of the device.
• Disconnect the device from the compressed air
source before repair and maintenance work as well
as before transport.
• When disconnecting the hose coupling, hold the
hose firmly in your hand to avoid injuries caused
by a hose recoiling.
• Look out for damage. Check the device for any
damage before putting it into operation. If the device
has any defects, it must not be put into operation
under any circumstances.
• Do not kink the hose of the device. Otherwise, it
may be damaged.
• NOTE! Observe the safety instructions of the man-
ufacturers of your inflatable articles.
• Do not remove any type plates - they are safety-rel-
evant components of the device.
• If you are inexperienced in handling the device, you
should be trained on how to use it safely.
6. Technical data
Mains power connection
Motor output
Operating mode
Compressor speed
Operating pressure
Theo. Suction capability
Effective output rate at 1 bar
Subject to technical changes!
*S3 25% = periodical intermediate duty with a duty cy-
cle of 25% (2.5 min based on a 10 minute period)
The noise emission values have been determined in
accordance with EN ISO 62841.
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Noise data
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
7.
Comply with the stipulated maintenance and safety in-
structions in the operating instructions. Remain attentive
at all times when working, and keep third parties at a safe
distance from your work area.
Even when the device is being used properly, there will
always be certain residual hazards that cannot be com-
pletely ruled out. The following potential hazards can
arise due to the type and design of the device:
• Unintentional starting up of the product.
• Damage to hearing if the stipulated hearing protec-
220-240 V~ 50Hz
1200 W
• Dirt particles, dust etc. can get irritate the eyes or
S3 25%
• Inhaling swirled up particles.
18000 rpm
8 bar
8. Unpacking
approx. 180 l/min
• Open the packaging and carefully remove the product.
approx. 90 l/min
• Remove the packaging material, as well as the pack-
www.scheppach.com
Pressure vessel volume
Protection category
Device weight
Cable length
Hose length
Sound power level L
wA
Sound pressure level L
pA
Uncertainty K
wA/pA
Residual risks
tion is not worn.
face despite wearing safety goggles.
aging and transport safety devices (if present).
6 l
IP30
9 kg
3 m
5 m
97 dB
75.9 dB
1.08 dB
GB | 27
