1.3. What's on the screen?
Icons are used on the Compact 10 touch screen to represent product functionality. Use this
section as a reference tool for understanding the graphics on the screen.
Some graphics only appear if you own a Compact 10 Speech. The table below
specifies which functions are available in Speech only. In addition, a blue icon in the
documentation indicates Speech only.
Icon Description
Decrease the magnification of the image
on the screen.
Take a snapshot of an image without
using text to speech.
Take a snapshot, scan for text, and read
the text.
Change the combination of colors used to
display the live view.
20
Compact 10 HD & Compact 10 HD Speech
Both or
Speech only
Both
Both
Speech only
Both
Occurrence
Easy and
Advanced modes
Easy and
Advanced modes
Advanced mode
Easy and
Advanced modes
