EN
8.3 How to use SolarFlow 800
8.3.1 Device Status
1. Charge/Discharge Status
• Charging: The battery is in charging status.
• Discharging: The battery is in discharging status.
• Standby: No input/output, device standby.
• Bypass: The battery is fully charged or charged to SOC limit or abnormal, and the solar energy directly
supplies power to the home.
2. Energy Flow
Click to view the energy flow diagram.
3. Product Preview Image.
4. Total Remaining Battery Capacity
Displays the total remaining battery capacity; click to view the remaining capacity of different batteries.
Device Status Energy Flow Battery
8.3.2 Smart Swicth
1.Turn on
When turned on, the device will be controlled by
the HEMS. Manual control is not available, you
can't use On-grid Settings、Battery Setting、Grid-
connected Standards、Power Distribution
Dtrategy
19
