EN
7.1.4 Installation Tools
Hexagon Wrench
Electric Drill
7.1.5 Grounding Setup
The AC cable contains earth wire so that grounding can be done directly with it.
For regions with special requirements, a grounding electrode (not included) can be used to complete the external
grounding.
7.2 Installation guide
7.2.1 Mounting the SolarFlow 800 on the wall
• Install the SolarFlow 800 in a location protected from direct sunlight.
• Solar cables are sold separately. Before finalizing the installation location, measure the distance between the solar
panel's connector and the SolarFlow 800's solar connector.
• The SolarFlow 800 is shipped without a Wi-Fi antenna installed. Attach the Wi-Fi antenna to the SolarFlow 800
before mounting the device on the wall.
1 2
1
4
Work Gloves
Marker Pen
Grounding hole for independent grounding
connection (M4 screws not included)
1 2
2
5
11
Tape Measure
2 2
1 1
3
