Installation in the Window Frame
Use the yellow adhesive strips for a test installation and the white adhesive strips
to attach the FRITZ!Smart Control 350. Stick the adhesive strips to the back of the
sensor and magnet.
1. Open the window all the way. Hold the
sensor with the positioning mark on top
and stick it in the window frame above the
window handle.
Do not install FRITZ!Smart Control
350 on the sill. Moisture can collect
there which would damage the
sensor.
2. Transfer the position of the sensor to the
sash and make a marking for the position
of the magnet 2 to 3 millimetres above it.
3. Attach the magnet to your marking on the
window sash so that the positioning marks
are aligned with each other.
FRITZ!Smart Control 350 is mounted and can
be configured.
