1. HANDLING
This guide does not replace the complete installation instructions. For further information,
please refer to the complete installation instructions.
Any equipment failure due to non-observance of manufacturer instructions and failure to respect applicable standards
and regulations or lack of maintenance shall render the warranty null and void.
1
Screen must
30° max
face upwards
Correct handling
2. HEATER INSTALLATION
350
MINI
T.Flow Hygro+
®
Kg
350
MINI
Kg
350
MINI
Kg
T.Flow Nano
®
WALL MOUNTED ON FRAME
350
350
MINI
MINI
Kg
Kg
350
MINI
Kg
If the heater is WALL-MOUNTED the installation must respect the requirements
of French standard NF DTU 60.1. Depending on the type of wall, it may be
necessary to install the heater on a tripod.
The water heater must be attached to the wall using screws and wall plugs suited
to the wall and the weight of the unit (in accordance with EN 60-335-1).
If the heater is installed ON A TRIPOD, it must always be fixed to the wall (at
least by the upper attachment bracket).
T.Flow Hygro Plus / T.Flow
®
2
NEVER handle using
the connection holes
350
MINI
Kg
Incorrect handling
350
MINI
350
Kg
MINI
Kg
250
MINI
350
MINI
Kg
Kg
ON THE GROUND
250
MINI 250
MINI
Kg
350
Kg
MINI
Kg
250
MINI
350
Kg
MINI
Kg
Nano
®
NEVER handle with
the screen face down
The water heater must be installed on a smooth,
horizontal surface (+/- 1°).
If the surface is not level, the water heater must be
made level using its legs.
If this precaution is not taken, condensation
evacuation issues may occur.
250
MINI
Kg
250
MINI
Kg
EN
5
MUST NOT be handled by
one person alone
Indicative weight
of filled water heater
• B100 T.Flow Nano:
176 kg
• B100 FAN-T.Flow Nano :
178 kg
