20
6.4
Modular means that starting from the basic unit Shotblaster machine, theoretically any
number of the same basic modules can be added. The base unit has the drive unit, the
control panel and one shot valve regulating lever. Otherwise it corresponds exactly to the
basic module which can be created from each basic module by adding the above-menti-
oned parts. This means that the blast width of the machine can be adapted to the condi-
tions depending on the application. Small areas or areas that are difficult to access can be
processed with a single system, large areas with double or multiple systems.
Multi-parts and exchangeables for the attachment of the
Extension Unit
Part
Multi-part
Exchange part
Wear & tear parts
Description
– Attachment of the shot valve control lever
– Metal bracket for hose feed-through
– Separating panels
– Rear wheel swing
– Back skirt
– Rubber sealings around magenetic frame
– Blast wheel
– Shot cage
– Interior linings
– Magnet frame
– Bracket for back skirt
– Back skirt
– Rubber sealings
– Shot stop in abrasive compartment
– Blast wheel cover
– Shot hose
– Poly-V belt of the Poly-V pulleys
– Turbine
The MOdUlaR SySTeM
