25
Change the position of the Hinge Bracket and the Angle Bracket as shown above. Replace the Bolts.
26
Reinstall the Pedal Plate with the uninstalled Bolts.
ACRYLIC PANEL INSTALLATION
A)
27 A) Use two strips of double-sided adhesive and stick them to the front of Centre Wheel Support.
B) Attach the Engraved Acrylic Panel to the Adhesive Strips on Centre Wheel Support.
B)
17
Video Instruction: bit.ly/nlrbuild
PARTS:
• • NIL
PARTS:
• • NIL
PARTS:
• • 2 x Double Sided Adhesive Strips
• • 1 x Engraved Acrylic Panel
