3. Tighten the nut counterclockwise. After adjusting the camera
to the desired angle, tighten the bracket nut clockwise.
Notes on wall mounting:
1. The wall on which the device is mounted must have a
loading capacity of at least 3 times the weight of the
device.
2. To avoid any damages or injuries, the device must be
securely fastened to the floor/wall as specified in the
installation instructions.
Basic Parameters
Product name: IMILAB EC3 Lite Outdoor Security Camera
Dimensions: 165 × 86 × 93 mm
Model: CMSXJ40A
Net Weight: 299 g
Power input: 12V 1A
Video code: H.265
Resolution: 2304×1296
Storage: MicroSD card (up to 256GB)
Operating Temperature: -30 ℃~ 60 ℃
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4GHz
05
