Note:
1. The MicroSD card needs to be purchased separately. The
camera can be used without a MicroSD card.
2. When inserting or removing the MicroSD card, please
disconnect the camera from the power supply. Use a MicroSD
card from IMILAB or another reputable manufacturer (up to
256GB). The recommended read and write speed of the
MicroSD card is at least U1/Class 10.
3. After installing the MicroSD card or resetting the device,
close the waterproof cover tightly before using it.
FAQ
Scan the QR code for Frequently Asked Questions.
Installing the Device
Wall mounting
1. Please make three marks on the wall first, and then drill
three holes at the positions. Drilling diameter of around
6.0mm, drilling depth of around 30mm.
2. Insert three plastic expansion
nuts into the holes. Put the base
plate on the wall. Secure the base
plate by inserting the screws into
the expansion nuts.
