STEINEL professional HF-360-2 DALI-2 Input Device Bedienungsanleitung Seite 63

11. Technical specifications
– Dimensions (H × W × D)
Hallway:
HF 360-2:
– Power consumption via DALI (12 – 22.5 V DC, no SELV):
To make sure you plan the system properly, please proceed
from a current consumption of 10 V and allow for an extra
20 % (as provided for in DALI-2 standard IEC 62386-101).
– Max. current consumption at an input voltage of 10 V:
– Typical current consumption at an input voltage of 16 V:
– Max. current consumption in accordance with IEC 62386-101:
– DALI startup-time:
– Reach:
HF 360-2:
Hallway:
Angle of coverage:
– Mounting height
– Sensor values:
– Protection class:
– Temperature range:
– Bluetooth frequency:
– HF 360-2 / Hallway frequency:
– Bluetooth transmission power:
– HF 360-2 / Hallway transmitter power:
* These values will not be exceeded in regular operation
and can be used as the basis for planning.
UP (concealed): 103 × 103 × 61 mm
AP (surface): 123 × 123 × 57 mm
UP (concealed): 103 × 103 × 66.5 mm
AP (surface): 123 × 123 × 62 mm
HF 360-2: 21 mA / 11 users
Hallway: 25 mA / 13 users
HF 360-2: 38 mA / 19 users
Hallway: 46 mA / 23 users
Relative humidity: 0 – 100 %
– 63 –
84 mA / 42 users
25 x 3 @ 2.8 m
Light measurement,
Temperature: 0 – 40 °C,
-20 °C bis +40 °C
2.4 – 2.48 GHz
5 dBm / 3 mW
GB
< 1 s
Ø 12 m
360°
2 – 4 m
IP 20
5.8 GHz
< 1 mW
