STEINEL professional HF-360-2 DALI-2 Input Device Bedienungsanleitung Seite 41

Product components, HF 360-2 for surface-mounted
installation
3.6
Surface-mounting adapter
A
B Load module
C Connecting terminal
D Sensor module
HF 360-2 detection zone
3.7
A
B
C
– 41 –
2.5 m
12 m
GB
D
