BATTERIES RECHARGING
Bring the machine on a levelled surface.
1.
Plug in batteries connector (1) placed in the rear part of the
machine, to the connector (3) of the battery recharger.
2.
Proceed to the recharging keeping the tank lifted (see under
paragraph "BATTERY INSTALLATION AND SETTING OF THE
BATTERY TYPE" in "BEFORE USE").
Maintain the connection with the battery recharger until the
indication of the end of charge is not visualized.
Never leave the batteries completely discharged even if the machine
is not used. In case of lead/acid batteries, please check the electrolyte
level every 20 recharging cycles and eventually top up with distilled
water at the end of the recharge. Never leave the batteries
discharged for more than two weeks.
Danger of gas exhalations and emission of corrosive liquids. Fire
danger: do not approach with free flames.
BATTERIES DISPOSAL
It is compulsory to hand over exhaust batteries, classified as
dangerous waste, to an authorized institution according to the
current laws.
BATTERIES CHARGE LEVEL INDICATOR
Activating the push button of the brush (2) the signal lamp of the
battery charge level (1) will come on.
When the signal lamp is in green colour it means that the battery
charge level is sufficient for the functioning of the machine.
If the signal lamp is in red colour it means that the battery charge
level is insufficient for the functioning of the machine and it is
necessary to recharge immediately the batteries (see under
"BATTERIES RECHARGING").
SQUEEGEE ASSEMBLY
With the squeegee support slightly lifted from the floor, slide the two
stud bolts (1) placed on the upper part of the squeegee, inside the
slots on the support. Block the squeegee by rotating the lever (2)
clockwise.
Insert the squeegee hose (3) into its coupling, respecting its position
as indicated in the figure.
ADJUSTMENT OF THE SQUEEGEE
In order to have a perfect drying result through the squeegee, the
rear rubber must have the lower bending uniformly adjusted in all its
length. For the adjustment, it is necessary to put oneself in working
condition and therefore the suction motor has to be switched on and
the brushes have to function together with the detergent solution.
The lower part of the rubber is too much bent
Take off the pressure rotating the wing nut (4) counterclockwise.
The lower part of the rubber is not much bent
Increase the pressure rotating the wing nut (4) clockwise.
The bending is not uniform
Adjust the squeegee inclination rotating counterclockwise the wing
nut (5) to increase the bending in the central part, or clockwise to
increase the bending on the extremities.
Height adjustment
Once that the pressure and inclination of the squeegee has been
adjusted, it is necessary to fix this optimum condition making touch
slightly the wheels onto the floor. Rotate counterclockwise the
registers (6) to lower the wheels or clockwise to raise them. Both
wheels must be adjusted in the same measure.
A label placed near the two registers (6) indicates rotation sense to
increase or reduce the height.
8
