Spectra II
Clean theTransfer Ribbon Drawing Roller
A soiled drawing roller can lead to a reduced print quality and can affect the transport of material.
•
Remove the printer cover.
•
Remove the transfer ribbon from the label printer.
•
Remove deposits with the roller cleaner and a soft cloth.
•
If the roller appears damaged, replace it.
•
Reload the transfer ribbon.
•
Close the printer cover.
Clean the Pressure roller
A soiled pressure roller can lead to a reduced print quality and can affect the transport of material.
CAUTION!
Pressure roller can be damaged!

Do not use sharp or hard objects to clean
the pressure roller.
•
Open the printer cover.
•
Turn the lever (A) counter clockwise to lift up the printhead (B).
•
Remove the labels and transfer ribbon from the label printer.
•
Remove deposits with the roller cleaner and a soft cloth.
•
Turn the roller (C) manually step by step to clean the complete roller (only possible when printer is switched off, as
otherwise the step motor is full of power and the roller is kept in its position).
•
To move the printhead down, turn the pressure lever in clockwise direction until it locks.
•
Reload labels and transfer ribbon.
•
Close the printer cover.
76
A
B
C
