GB
No. Component
8 Battery**
9 Handle
10 Baffle
11 Fill level indicator
12 Handle of grass catcher
13 Grass catcher
Height-adjustable handlebar, consisting of:
14 Lower brace
15 Height adjustment screw
16 Upper brace
17** Charger**
* depending on the model, see technical data.
** depending on the scope of supply.
2.6.2 Product overview (02, 03) – comfort
and premium
No. Component
1 Handle
2 Operator presence control
3 Start button
4 Central cutting height adjustment
5 Cutting blade
6 Battery compartment cover
7 Battery compartment
8 Battery**
9 Handle
10 Baffle
11 Fill level indicator
12 Handle of grass catcher
13 Grass catcher
Height-adjustable and folding handlebar, con-
sisting of:
14 Rotary/snap-in joints with quick-release
lever
15 Lower brace
38
No. Component
16 comfort: Rotary joint with quick-release
lever
premium: Quick-release lever for upper
brace
17 comfort: Upper brace, folding
premium: Upper brace, telescopic
18 Charger**
19 premium: Cockpit
* depending on the model, see technical data.
** depending on the scope of supply.
2.7 Scope of supply
The items listed here are included in the standard
scope of supply. Check that all items are present:
No. Component
1 Lawnmower
2 Grass catcher (unassembled/partially
assembled)*
3 Handlebar (unassembled/partially as-
sembled)*
4 Mulch insert*
5 Battery**
6 Charger**
* depending on the model, see technical data.
** depending on article number, see technical da-
ta.
2.8 "maxRun" cockpit (04)*
* depending on the model, see technical data.
Controls
No. Meaning
1 Start button
2 Operator presence control
3 ON/OFF button for cockpit, with status
LED
4 "Eco mode" button, with status LED
Displays
No. Meaning
5 Charge status display for battery
3.25 Li | 3.85 Li | 38.5 Li | 385 Li
Product description
