EX-1330M
5. Driver Installation
3. Execute the 'Run RTK_NIC_DRIVER_INSTALLER.sfx.exe' and follow the instructions of the
installation manager.
4. After successful installation, network connection 1 is displayed in the device manager as
'Ethernet Port #1'.
5. Now set DIP switch 2 to the ON position, while DIP switches 3 & 4 remain in the OFF position.
The operating system will now automatically install network port 2, which will also appear in
Device Manager as 'Ethernet Port #2'. If the installation fails, please set the DIP switch back to
OFF and then ON again!
6. Now set DIP switch 3 to ON and port 3 will be added.
7. Now set DIP switch 4 to ON and port 4 will be added.
CHECK INSTALLED DRIVER
Open the >Device manager<. Now you should see at „Network Adapters" the following
new entry's:
If you see this or a similar information the EX-1330M is installed correctly.
6. Cleaning
To clean the unit, use only a dry, lint-free cloth and apply light pressure to remove dirt. Take care
not to leave any fibres of the cloth in the connectors.
Never use a damp or wet cloth for cleaning!
