3. Layout, Connections & LED
3.2 Connections
RJ45 Port:
87654321
Status LEDs:
LED Name
Link/Act
Speed
USB 3.2 Gen 1 C-Port:
Note!
By dual assignment of the pins, the USB Type-C plug can be plugged into the port on both
sides.
© Copyright 2025 by EXSYS Vertriebs GmbH. All Rights Reserved
RJ45 Port
Pin
1
2
3
Color
Steady on:
Green
Blinking:
Off:
Off:
Yellow
Steady on:
Signal
Pin
BI_DA+
4
BI_DC+
BI_DA-
5
BI_DB+
6
LED Function
The Connection on the Ethernet port is built
and Active
Transferring Ethernet Data
Ethernet Port Disconnected
10/100Mbps Mode
Gigabit (1000Mbps) Mode
12
EX-1330M
Signal
Pin
Signal
7
BI_DD+
BI_DC-
8
BI_DD-
BI_DB-
